FL(IE1) series premium efficiency three phase asynchronous motor

FL(IE1) series is cast iron housing electric motor with IEC 60034-30 efficiency standard IE1 for general purpose applications, dimensions follow IEC60072-1. Excellent performance, low noise and vibration, high reliability, easy operation

Message

$44.80

Have chosenThere are no options selected.

*Output Power
--- Please Select ---
Start To Order

Add To Cart Successfully!

SEND INQUIRY
FL(IE1) series premium efficiency three phase asynchronous motor

FL(IE1) series premium efficiency three phase asynchronous motor

FL(IE1) series is cast iron housing electric motor with IEC 60034-30 efficiency standard IE1 for general purpose applications, dimensions follow IEC60072-1. Excellent performance, low noise and vibration, high reliability, easy operation

  • Item No.FL(IE1) Electric Motor
    MOQ1 Piece

Available Options

Output Power
Customization:

3d-iconOnline customization Customise Now

Customized logo (Min. Order: 1*20ft container Piece)

Customized packaging (Min. Order: 10*20ft container Piece)

Add Request About This Product
Max file 5MB each
If lager file please send us email

Quantity:

From $44.80 / Piece
$44.80
You save $ -44.80

If you have your own design, please contact us, there will have a professional customer service to communicate with you.

Don't have your files right now?No worries, Check out our art tips for more information.

If over 500pcs, mass production will start until pre-production sample has been approved.

Est. 7 days production

Packaging & Delivery

Selling Units:
20ft container
Lead Time:
Quantity(20ft container)12 - 56 - 1011 - 30>30
Est. Time(days)30506090To be negotiated



Description

FL(IE1) series three phase asynchronous motor is a kind of totally enclosed fan-cooled squirrel-cage induction motor. The efficiency class is in accordance with IEC 60034-30 IE1 efficiency standard.
FL series motors have a lot of futures such as excellent performance, low noise and vibration, high reliability, easy operation and etc. Moreover, FL series motors have the same dimensions and output power with IE2/IE3/IE4/IE5 series, which follows IEC60072-1, therefore FL series could replace all IEC standard motors directly. Motors could be equipped with oil changing device without stopping, and reserved the space of thermistor and heater for end users



Technical Parameters

Rated Power:0.55kW-1000kW

Frame Size:H80-H450

Frame Material:Cast Iron

Rated Voltage:220V-1140V

Rated Frequency:50Hz/60Hz

Ingress protection:IP54/IP55/IP56/IP65/IP66

Insulation Class:F/H/C

Work Duty:S1-S6



Technical Bright Spots & Consumer Benefits

Technical Bright Spots

1. High energy-efficiency
2. Its scientifically reasonable structure provides reserved space to customers
3. Energy conservation and environment friendly
4. Low noise and low vibration

Consumer Benefits

1. Improve the productivity, Saving energy and reduce the cost.
2. It can directly replace low efficiency motors,be easy to market promotion
3. It is easy for customers to replace/choose parts in the special area
4. Provide the comfort on the production line
